Ojmar OTS 40 Batteryless

Ojmar OTS40 Batteryless

The first human powered smart lock. A simple push generates all the energy the lock needs to operate, online or offline. Designed to make life easier and help organisations meet the highest ESG and LEED standards.

    • Battery-free, self-powered locking
    • Made from recycled and recyclable plastics and components
    • Modular and scalable – rearrange layouts without hardwiring
    • Online and offline operation with no downtime or maintenance required
    • Centralised management via the cloud or on-premise for full remote control
    • Environmental Product Declaration (EPD) verified
    • Compliant with European EPBD and US-based Building Performance Standards

    Access via

    • NFC via mobile
    • RFID card
    • Wristbands
    • Fobs
    • Technogym key
    • Stickers
    • Transponders

    Configuration

    • Fully configurable by the Facility Manager.
    • Automatic connection of the locks to Ojmar’s cloud software.
    • Integration with third-party software via SDK.

    Compatibility

    • Metal furniture
    • End customer credentials
    • Facility credentials

    Maintenance

    • No batteries, no wires required.
    • Configurable usage reports.
    • Offline mode in case of gateway failure.
    • FW update via NFC.
    • Power supply point to update FW on the back side of the lock.

    Security

    • Encrypted communications.
    • Robust construction – all components are protected inside the housing.

    Technologies

    Authentication mode: RFID

    RFID standards: MIFARE®(DESFire EV1 &EV2, Ultralight, Ultralight C, Classic1K/4K 4B and 7B UID – ISO/IEC 14443)

    Reading: UID / Sector / Application / File / Page

    Credentials: RFID cards, Wristbands, Fobs, Technogym key, Stickers, Transponders & Smartphone

    Power supply

    Push Power Technology. No batteries. No wires. No accumulators.

    Configuration

    Fully configurable by the Facility Manager.

    Compliance

    CE, FCC

    Warranty

    2 years (extensible upon demand SLA)

    Dimensions

    108mm x 65mm x 35mm

    Battery-free

    The first batteryless smart lock. No batteries. No wires. No waste.

    Circular materials

    Manufactured using recycled and recyclable plastics and components. Packaging is 100% recycled and plastic-free.

    Maintenance-free operation

    Our Push Power Technology allows locks to be self-powered via user interaction, thereby eliminating the maintenance costs associated with conventional smart locks.

    Certified sustainability

    ISO 14001, ISO 9001 and ISO 27001 are met.

    Compliant with European EPBD and US-based Building Performance Standards (BPS, such as NYC’s LL97).
